54W 72W 1200X600mm LED Panel light
Item No. : GL-PL-54W02/GL-PL-72W02
Certificates: Meet CE&RoHS standard
LED Sources: 2835SMD
Input Voltage: AC85-265V
Driver: External Type
Warranty: 3 years
Description
Features:
1, Imported Slim Light Guide Plate could assure hight brightness, with light transmission rate at 80%
2. External high power factor Power supply.
3, Warranty Policy : 2 years warranty with original written warranty , 20,000 switch cycles(on/off switching)
4 .Low lighting dissipation/sink
The light source is the low lighting dissipation and high-bright LED, which the dissipation is less than 30% during 50000hours.
5. SMD 3014 LEDs for the Light source, high brightness.
6.Environment protection:While working, no ultraviolet light and infrared light radiation. And never contain any hazardous substance, such as Mercury.
7. Eyes protection: Diffused cover ,never see LED ,good for eyes; adopting constant current power supply, no flashing, no harm for eyes.
8, Super slim design, 11mm thickness, fashion and good looking.
Technical Parameter:
| Modle No. | GL-PL-54W02 | GL-PL-72W02 |
| Material | Aluminum Frame+Acrylic plate | Aluminum Frame+Acrylic plate |
| LED Brand | Epistar | Epistar |
| Power | 54W | 72W |
| Led QTY | 280pcs 2835 | 360pcs 2835 |
| Input Voltage | AC85-265V | AC85-265V |
| Frequency Range | 50-60Ｈz | 50-60Ｈz |
| Lumen Output | 3500-3800lm | 4800-5000lm |
| CRI | Ｒa＞75 | Ｒa＞75 |
| Lighting Angle | 155 º | 155 º |
| Life Span | 50000hours | 50000hours |
| Color Temperature | Warm white(3000k) Natural white(4500K) Cool white(6000K) |
Warm white(3000k) Natural white(4500K) Cool white(6000K) |
| Working Temperature | –20-+50 ° C | –20-+50 ° C |
| Storage Temperature | 0 - 50 ° C | 0 - 50 ° C |
| Junction Temperature | 10 % ~ 90 % RH | 10 % ~ 90 % RH |
| Product size | 1200*600*11mm | 1200*600*11mm |
| Packing size | 1260*640*45mm | 1260*640*45mm |
| Net / Gross weight | 8.8/10kg | 8.8/10kg |
Applications:
Hotels,Meeting rooms,Offices,hospitals, Schools, Factories, Museums,Homes,Decorating lights, Showing and wall lights,Retail stores, Commercial lightings, Shopping malls, Supermarkets,Kitchens, Home indoor lightings and so on.
Packing:
