15W 2835SMD LED panel down light

Item No. : GL-PL-15W2835
Certificates: Meet CE&RoHS standard
LED Sources: 2835SMD
Input Voltage: AC85-265V
Driver: External Type
Warranty: 3 years

Description

Features:


1,  Aluminum Die casting housing and frosted cover, it's with light transmission rate at 80%
2.  External high power factor Power supply.
3,  Warranty Policy : 3 years warranty with original written warranty , 20,000 switch cycles(on/off switching)
4 .Low lighting dissipation/sink
The light source is the low lighting dissipation and high-bright LED, which the dissipation is less than 30% during 50000hours.
5. SMD2835 LEDs for the Light source, high brightness.
6.Environment protection:While working, no ultraviolet light and infrared light radiation. And never contain any hazardous substance, such as Mercury.
7. Eyes protection: Diffused cover ,never see LED ,good for eyes; adopting constant current power supply, no flashing, no harm for eyes.
8, Super slim design, 11mm thickness, fashion and good looking.

Technical Parameter:
Modle No. GL-PL-9W2835 GL-PL-15W2835
Material Aluminum Die cast+Frosted cover Aluminum Die cast+Frosted cover
LED Brand Epistar Epistar
Power 9W 15W
Led QTY 18pcs 2835 30pcs 2835
Input Voltage AC85-265V AC85-265V
Frequency Range 50-60z 50-60z
Lumen Output 90-100lm/Watt 90-100lm/Watt
CRI a75 a75
Lighting Angle 155 º 155 º
Life Span 50000hours 50000hours
Color Temperature Warm white(3000k)
Natural white(4500K)
Cool white(6000K)
Warm white(3000k)
Natural white(4500K)
Cool white(6000K)
Working Temperature –20-+50 °   C –20-+50 °   C
Storage Temperature 0 - 50 ° C 0 - 50 ° C
Junction Temperature 10 % ~ 90 % RH 10 % ~ 90 % RH
Product size 148x28mm 175x28mm
Hole size 120mm 145mm

Applications:

Hotels,Meeting rooms,Offices,hospitals, Schools, Factories, Museums,Homes,Decorating lights,  Showing and wall lights,Retail stores,  Commercial lightings, Shopping malls, Supermarkets,Kitchens,   Home indoor lightings and so on.
