0.6m 20W LED Triproof Light IP65
Item No. : GL-2835WF2-20W
Power: 20W
Certificates: Meet CE&RoHS standard
LED Sources:2835SMD LEDs
Driver: Build-in Type
Warranty: 3 years
IP rate: IP65
Description
- Features:
- 1. Own complete production lines to ensure the best quanlity and cost control
- 2. Complete test equipments, including EMC,IES,Hi-pot and 2M intergrating sphere etc
- 3. Patent design for structure,rotatable end cap and isolated power supply
- 4. Lower constant current to drive the LED to insure the lifespan and light decay
- 5. 300,000 monthly production ability to ensure the timly delivery
- 6. 3 years warranty time.
- 7. OEM and ODM service
- 8. IP65.
- Technical Parameter:
-
Product Name
0.6M 20W LED Triproof light IP65
Item code
GL-2835WF2-20W
Dimension
675*135*93mm
LED Type
SMD 2835
LED Qty
120 LEDs
Input Voltage
AC100-240V/AC100-277V
Power
20W
Luminous Flux
1600-1800LM
Light Efficacy
85-95 LM/W
Power Factor
>0.9
CRI
>80
Housing
PC housing + PC striped/Frosted cover + Aluminum board
LED Working Current
50-55 mA
LED Beam Angle
135 degree
Color Temperature
WW
3000-3500K 4000-4500K
PW
5000-5500K
CW
>6000K
Lifespan
30,000-50,000hrs
Packing
6PCS/CTN
Carton size
74*29*50CM
Commercial lighting
Supermarket/Shops/ Exhibition hall/Parking place/gas station, etc.
Public lighting
library/School/Tunnel/Metro/Bus/Train/Bus station, railway station, airport, etc.
Industrial lighting
Factory/Warehouse, etc.
Input voltage
AC100-240V/AC100-277V
Working voltage
DC30-40V
Superior
high efficiency and energy saving more than 70%
Strong shape
with PC housing + PC cover
Special design with Stainless steel clips
Aluminum board
Better heat dissipation
Impact aging test
100% for 24-48 hours impact aging test before packing
IP65 Waterproof/Dust-proof/Moisture-proof
-
