T8 3014SMD LED Tube Light 10W 18W 20W 25W
Item No. : GL-T8-3014-F2-10W
Certificates: Meet CE&RoHS standard
Lampshade: Clear and Frosted
Length: 0.6m, 1.2m, 1.5m
Lifespan: 50,000 hours
Warranty: 3 Years
Description
Special Features:
1. Adopted High brightness Epistar 3014SMD LEDs. (70%-80% Energy-saving over fluorescent tubes)
2. Build-in Zener Diodes.(If one led fail, the remaining LEDs will still work)
3. Build-in High Efficiency driver, Power factor can be above 0.95.
4. Standard Length 60cm, 120cm and 150cm.
5. Wide voltage input 85-265V AC.
6. Work without ballast, Instant soft-start.
7. No RF interference, No flickering and buzzing.
8. No Mercury and other hazardous materials, fully RoHS compliance.
9. Frosted and Clear cover are available. (Frosted cover, never see LEDs, good for eyes)
10. High Shock/vibration resistant(not easy to be broken)
11. 3 years warranty time.( Working hours can be up to 50,000 hrs)
Technical Parameter:
| Item No. | GL-T8-3014-F2-10W | GL-T8-3014-F4-18W | GL-T8-3014-F4-20W | GL-T8-3014-F5-25W |
| Size | 600X26mm | 1200X26mm | 1200X26mm | 1500X26mm |
| Color temperature | Warm white:3000K Natural white:4500K Pure white:6000K |
Warm white:3000K Natural white:4500K Pure white:6000K |
Warm white:3000K Natural white:4500K Pure white:6000K |
Warm white:3000K Natural white:4500K Pure white:6000K |
| Type of LEDs | SMD3014 | SMD3014 | SMD3014 | SMD3014 |
| LEDs quantity | 96pcs | 168pcs | 192pcs | 220pcs |
| Input Voltage | AC85-265V | AC85-265V | AC85-265V | AC85-265V |
| Power | 10W | 18W | 20W | 25W |
| Lumen | 880LM | 1650LM | 1750LM | 2150LM |
| Driver | Build-in constant current driver, PF>0.95 | Build-in constant current driver, PF>0.95 | Build-in constant current driver, PF>0.95 | Build-in constant current driver, PF>0.95 |
Application:
1, Office building, Shops, Shopping mall, Supermarket;2, School, Hospital, Exhibition hall; 3, Warehouse market lighting; 4, Factory; 5, Airport
Aging Test:
Packing:
