24X1W LED Wall washer 02
Model No.:GL-WW24-24W02
Driver: Build-in type High Efficiency driver
Certificates: CE&RoHS
Warranty: 3 Years
Light Sources: Edison/Cree
Lifespan: 50,000hrs
Description
Features:
1.Work with RGBW LED Controller with four or more channels.
2.Durable and completely corrosion resistance --Good heat dissipation performance. --Silicon rubber sealing technology .securing perfect waterproof performance of IP65.
4.High temperature resistant, anti-aging.
5.The unique optical PMMA lens ensure the brightness maintenance and projection effect 3mm tempered glass cover, strong protection and good optical function.
6. No Mercury and Other Hazardous Materials, Fully CE ad RoHS compliant.
7.Exquisite appearance.
8.Housing: Alluminum alloy with extrusion technology and oxidation treatment.
| Modle No. | GL-WW24-24W02 |
| Material | Aluminum+Toughtened glass |
| LED Brand | Epistar |
| Power | 24W |
| Led QTY | 24 pcs |
| Input Voltage | AC85-265V |
| Frequency Range | 50-60Ｈz |
| Lumen | 90-100lm/w |
| CRI | Ｒa＞75 |
| Lighting Angle | 15,25,30,45 and 60 degree |
| Total Harmonic Distortion (THD) | 8% |
| Life Span | 50000hours |
| Color Temperature |
Warm white(3000k) RGB/Blue/Green/Red |
| Working Temperature | –20-+50 ° C |
| Storage Temperature | 0 - 50 ° C |
| Junction Temperature | 10 % ~ 90 % RH |
| Housing Color | Grey Housing Clear Toughtened glass |
| Dimension | 85X50X1000mm |
Applications:
1. Lights for billboard, architecture, building walls, commercial building projection.
2. Lights for canopy,corridor,window,archway, court,parking lot,gymnasium,dock,park.
3. Lights for bar, disco, pub, club, show and events, tree decoration,sculpture.
4. Other indoor lighting or other outdoor lighting.
Aging Test:
