0.6M 30W LED Triproof light IP65

Item No. : GL-2835WF2-30W
Power: 30W
Certificates: Meet CE&RoHS standard
LED Sources:2835SMD LEDs
Driver: Build-in Type
Warranty: 3 years
IP rate:  IP65

Description



  •  Features:
  • 1. Own complete production lines to ensure the best quanlity and cost control
  • 2. Complete test equipments, including EMC,IES,Hi-pot and 2M intergrating sphere etc
  • 3. Patent design for structure,rotatable end cap and isolated power supply
  • 4. Lower constant current to drive the LED to insure the lifespan and light decay
  • 5. 300,000 monthly production ability to ensure the timly delivery
  • 6. 3 years warranty time.
  • 7. OEM and ODM service
  • 8. IP65.
  • Technical Parameter:
  • Product Name

    0.6M 30W LED Triproof light IP65

    Item code

    GL-2835WF2-30W

    Dimension

    675*135*93mm

    LED Type

    SMD 2835

    LED Qty

    180 LEDs

    Input Voltage

    AC100-240V/AC100-277V

    Power

    30W

    Luminous Flux

    2400-2600LM

    Light Efficacy

    85-95 LM/W

    Power Factor

    >0.9

    CRI

    >80

    Housing

    PC housing + PC striped/Frosted cover + Aluminum board

    LED Working Current

    50-55 mA

    LED Beam Angle

    135 degree

    Color Temperature

    WW

    3000-3500K 4000-4500K

    PW

    5000-5500K

    CW

    >6000K

    Lifespan

    30,000-50,000hrs

    Packing

    6PCS/CTN

    Carton size

    74*29*50CM

    Commercial lighting

    Supermarket/Shops/ Exhibition hall/Parking place/gas station, etc.

    Public lighting

    library/School/Tunnel/Metro/Bus/Train/Bus station, railway station, airport, etc.

    Industrial lighting

    Factory/Warehouse, etc.

    Input voltage

    AC100-240V/AC100-277V

    Working voltage

    DC30-40V

    Superior Taiwan chip

    high efficiency and energy saving more than 70%

    Strong shape

    with PC housing + PC cover

    Special design with Stainless steel clips

    Aluminum board

    Better heat dissipation

    Impact aging test

    100% for 24-48 hours impact aging test before packing

    IP65 Waterproof/Dust-proof/Moisture-proof

  •
